1. Four-core optical fiber transmits TMDS signals, with zero signal attenuation, supporting ultra-long transmission distances, up to 100 meters.
2. Compatible with all devices that comply with HDMI Association standards.
3. Comply with HDMI2.1 version specifications.
4. Imported photoelectric conversion chips to improve compatibility, stability and service life. Resolution supports 8K@60Hz 4K@120HZ 4:4:4, and supports 3D visual effects.
5. Supports HDCP 2.3/HDR10/EDID/CEC/DDC/ARC/eARC.
6. 1-100 meters supports ARC (audio return), 1-30 meters supports eARC (audio return).
7. Data rate: 48Gbps bandwidth.
8. Plug and play, no external power supply required, no driver required.
9. Silicon-line driver chip, 250mW ultra-low power consumption.
10. Zinc alloy integrated shell: anti-electromagnetic interference, increased wear resistance, and improved service life. Applicable.
scenarios:
1. High-definition long-distance video conferencing, high-quality image transmission
2. Large-screen display multimedia display control system
3. Remote flat-panel TV, spliced TV wall display
4. Medical image display and high-definition projection system
5. Villa high-definition video monitoring
6. Large hotels, classrooms, large outdoor advertising screens
7. Public security high-definition camera images
8. Large hotels, families, schools monitoring, security
9. Aviation aircraft video imaging system
10. Subway, airport. Ferry, shopping center, etc. Information delivery
11. Home theater
12. Carry out application demonstrations based on ultra-high-definition video in the fields of culture, education and entertainment, security monitoring, medical health, intelligent transportation
13. Industrial manufacturing, etc.
